Lift Table Cart

Name: Lift Table Cart
Brand: Beacon
Price: 1008.59 USD
Availability: InStock

Lift Table Cart - Small Portable Scissor Lift - BCART-S & BCART-D Series

Beacon® BCART-S-FR Series

The sturdy Lift Table Cart is ideal for use in many industrial applications, such as die handling, order-picking, assembly lines, lifting loads, and transporting products. These Small Portable Scissor Lift units are operated via a foot or hand-actuated single-speed hydraulic pump which features an overload protection valve. Each cylinder has an internal hydraulic velocity fuse. Single and double-scissor models are available.

Starting at: $1,008.59

See chart below and click a model number

Product Details

Size: Platform sizes range from 17-3/4" to 25-1/2" wide and from 30" to 45-1/4" long.
Service Range: Units lower as far as 10" and raise to as high as 63-3/4".
Installation: Safety stops prevent empty deck from lowering during maintenance, and tilt-up table top creates a safe and easy maintenance experience.
Color: These units are Beacon blue.
Weight: 92 to 385 lbs.
Operation: Foot or hand-actuated hydraulic pump operation.
Capacity: Capacities range from 300 to 1,000 lbs.
Standard: Units are highly maneuverable due to their two 8" x 1-1/2" rigid front and two 5" x 1-1/2" swivel rear polyurethane casters. Swivel casters feature brakes and are protected by guards.
Options: The Lift Table Cart is available with a stainless steel cover as well.
Surcharge: Due to supply chain disruption, inflation or material shortages - tariffs or surcharges may apply to current published pricing. Some longer lead times may be incurred. Freight charges will be added to published pricing.
Note: Testing, adjustments, training and scheduled maintenance procedures by others.

BCART-400-D-HR 360° View

Documents

Prop. 65 WARNING

Lift Table Cart - BCART-S-FR Series
Model No.	Scissor Type	Lowering Method	Platform Size (W x L)	Raised Height	Lowered Height	Capacity (LBS)	Price
1) BCART-300-S-FR	Single	Foot	17¾"x30"	31"	10"	300	$1,008.59
2) BCART-600-S-FR	Single	Foot	19"x33"	33"	13¼"	600	$1,282.01
3) BCART-1000-S-FR	Single	Foot	24"x40½"	35½"	13½"	1,000	$1,326.54

4) BCART-300-D-FR	Double	Foot	19½"x33"	56"	17"	300	$1,639.56
5) BCART-600-D-FR	Double	Foot	23¼"x33"	53"	11¾"	600	$1,967.73
6) BCART-1000-D-FR	Double	Foot	24"x40½"	61"	11¾"	1,000	$2,325.03
7) BCART-1000-S-HR	Single	Hand	25½"x45¼"	36¼"	12½"	1,000	$1,304.89
Lift Table Cart - BCART-S-FR Series (continued)
Model No.	Scissor Type	Lowering Method	Platform Size (W x L)	Raised Height	Lowered Height	Capacity (LBS)	Price
8) BCART-400-D-HR	Double	Hand	23⅝"x35-7/16"	65"	18⅛'	400	$1,596.27
