SCISSOR LIFT

Beacon^® Scissor Lift technology can be the most essential equipment for raising or lowering in the work place. The Lift Table is engineered to assist in industrial ergonomics powered by hydraulic. Hydraulic Scissor Lift is design as a proven technology, standing the test of time. Capacities are available from 400 lbs. to 100,000 lbs. evenly distributed. All Hydraulic Scissor Lift Tables are quoted the capacity within its deck size keeping with a uniformly distributed load. Beacon^® brand illustrates its dedication to hydraulic scissor lift table technology.

Click one of the 21 highlighted links below for pricing and product descriptions of our Scissor Lift.

1) Hydraulic Lift View 43 Models The BEHLT features a deck size of 24"min. width to 144" max. length. Capacities ranging from 1,000 to 12,000 lbs. with a raised height of up to 82".	2) Hydraulic Scissor Lift View 5 Models This BEHLTS has a deck size of up to 24" min. width to 48" max. length. Capacity ranges from 1,000 to 5,000 lbs. with a raised height of 35".
3) Narrow Scissor Lift View 2 Models The BEHLT-N features a deck size of 16"min. width to 48" max. length. Capacities ranging from 1,000 to 2,000 lbs. with a raised height of up to 32".	4) Low Scissor Lift View 7 Models The BEHLTX features a deck size of 36"min. width to 60" max. length. Capacities ranging from 1,000 to 3,500 lbs. with a raised height of up to 39".
5) Ground Lift Table View 13 Models This BEHLTG lowers items to the floor for efficient loading and unloading practices. Features a raised height of up to 48", a lowered height of 1/2", and a deck size of 44" min. width to 70" max. length. The capacity ranges from 2,000 to 4,000 lbs.	6) Economy Scissor Lift View 3 Models Our BEHLT-WS can lift materials to the correct working height with a deck size of 24" min. width to 48" max. length. The capacity of this unit is 1,500-lbs. with a raised height of up to 36".
7) Stationary Scissor Lift View 2 Models This BEHU has a unique "U" center design to accommodate pallet truck loads. This electric hydraulic equipment that has a platform size of either 52-1/2" x 55-3/4" or 53-1/2" x 63". Features capacities of 2,000 or 3,000 lbs.	8) Stainless Steel Adjustable U Table View 1 Product This BEHU-SS has a unique "U" center design to accommodate pallet truck loads in a sanitary environment. This electric hydraulic equipment has a platform size of either 50" x 59". Features a capacity of 1,200 lbs.
9) Small Scissor Lift View 4 Models Our BCDL has a deck size of 18" min. width to 60" max. length. This unit is perfect for working in tight spaces. Capacities ranging from 500 to 2,000 lbs. with a raised height of up to 43".	10) Small Lift Table View 8 Models The BEHLTSD features our smallest deck size of 12" wide x 28" Long with our largest deck 48" wide x 48" long. Features a capacity range from 500 to 5,000-lbs. with a raised height of up to 51".
11) Double Scissor Lift View 10 Models This BEHLTD has a deck size of 34" min. width to 88" max. length. Features capacities from 1,000 to 5,000 lbs. with a raised height of up to 84".	12) Scissor Lift Mechanism View 2 Models This BCLTPB include a double acting scissor. This unit is constructed of heavy-duty steel. Capacity ranges from 1,000 to 5,000 lbs. with a raised height of 89".
13) Upright Scissor Lift View 18 Models The BDSL has a deck size of 30" min. width to 132" max. length. Capacities range from 2,000 to 6,000 lbs. with a raised height of up to 162".	14) Electric Scissor Lift View 12 Models The BTSL features a deck size of 30" min. width to 144" max. length and includes safety restraint bars. Capacity ranges from 3,000 to 6,000 lbs. and has a raised height of up to 270".
15) Tall Scissor Lift View 4 Models The BQSL features steel construction and a deck size of 60" min. width to 144" max. length. Capacity ranges from 3,000 to 6,000 lbs. with a raised height of up to 356".	16) Hydraulic Lift Table View 35 Models The BMLT has a deck size of 48" min. width to 132" max. length. Capacity ranges from 15,000 to 30,000 lbs. with a raised height of up to 92".
17) Long Scissor Lift Table View 8 Models This BEHLT-TL features a deck size range from a 30" width to 144" length up to a 48” width to 180” length. Medium duty design with capacities ranging from 2,000 to 4,000 lbs. with a raised height up to 58".	18) Scissor Lift Table View 12 Models Our BHLTTL has a deck size of 24" min. width to 216" max. length and features an extra-long platform. Capacity ranges from 2,000 to 12,000 lbs. with a raised height of up to 68".
19) Heavy Capacity Scissor Lift View 42 Models This BMLTDW Lift features heavy-duty steel construction and an extra-wide platform. Capable of bearing loads from 25,000 to 60,000 lbs. and has a raised height of up to 92".	20) Hydraulic Platform Lift View 20 Models The BMLTDL features a deck size of 48" min. width to 264" max. length. Capacity range is from 30,000 to 60,000 lbs. with a raised height of up to 92".
21) Heavy Duty Scissor Lift View 42 Models The BMLTQD has a deck size of 96" min. width to 264" max. length. Capacities range from 50,000 to 120,000 lbs. with a raised height of up to 92".

Beacon World Class Lift Table - BEHLT series

Hydraulic Lift

View 43 Models

The BEHLT features a deck size of 24"min. width to 144" max. length. Capacities ranging from 1,000 to 12,000 lbs. with a raised height of up to 82".

Hydraulic Scissor Lift

View 5 Models

This BEHLTS has a deck size of up to 24" min. width to 48" max. length. Capacity ranges from 1,000 to 5,000 lbs. with a raised height of 35".

Narrow Scissor Lift

View 2 Models

The BEHLT-N features a deck size of 16"min. width to 48" max. length. Capacities ranging from 1,000 to 2,000 lbs. with a raised height of up to 32".

Low Scissor Lift

View 7 Models

The BEHLTX features a deck size of 36"min. width to 60" max. length. Capacities ranging from 1,000 to 3,500 lbs. with a raised height of up to 39".

Ground Lift Table

View 13 Models

This BEHLTG lowers items to the floor for efficient loading and unloading practices. Features a raised height of up to 48", a lowered height of 1/2", and a deck size of 44" min. width to 70" max. length. The capacity ranges from 2,000 to 4,000 lbs.

Economy Scissor Lift

View 3 Models

Our BEHLT-WS can lift materials to the correct working height with a deck size of 24" min. width to 48" max. length. The capacity of this unit is 1,500-lbs. with a raised height of up to 36".

Beacon World Class Adjustable U Table - BEHU series

Stationary Scissor Lift

View 2 Models

This BEHU has a unique "U" center design to accommodate pallet truck loads. This electric hydraulic equipment that has a platform size of either 52-1/2" x 55-3/4" or 53-1/2" x 63". Features capacities of 2,000 or 3,000 lbs.

Stainless Steel Adjustable U Table

View 1 Product

This BEHU-SS has a unique "U" center design to accommodate pallet truck loads in a sanitary environment. This electric hydraulic equipment has a platform size of either 50" x 59". Features a capacity of 1,200 lbs.

Small Scissor Lift

View 4 Models

Our BCDL has a deck size of 18" min. width to 60" max. length. This unit is perfect for working in tight spaces. Capacities ranging from 500 to 2,000 lbs. with a raised height of up to 43".

10)

Small Lift Table

View 8 Models

The BEHLTSD features our smallest deck size of 12" wide x 28" Long with our largest deck 48" wide x 48" long. Features a capacity range from 500 to 5,000-lbs. with a raised height of up to 51".

11)

Double Scissor Lift

View 10 Models

This BEHLTD has a deck size of 34" min. width to 88" max. length. Features capacities from 1,000 to 5,000 lbs. with a raised height of up to 84".

Beacon World Class Dual Scissor Lifts - BCLTPB series

12)

Scissor Lift Mechanism

View 2 Models

This BCLTPB include a double acting scissor. This unit is constructed of heavy-duty steel. Capacity ranges from 1,000 to 5,000 lbs. with a raised height of 89".

13)

Upright Scissor Lift

View 18 Models

The BDSL has a deck size of 30" min. width to 132" max. length. Capacities range from 2,000 to 6,000 lbs. with a raised height of up to 162".

14)

Electric Scissor Lift

View 12 Models

The BTSL features a deck size of 30" min. width to 144" max. length and includes safety restraint bars. Capacity ranges from 3,000 to 6,000 lbs. and has a raised height of up to 270".

15)

Tall Scissor Lift

View 4 Models

The BQSL features steel construction and a deck size of 60" min. width to 144" max. length. Capacity ranges from 3,000 to 6,000 lbs. with a raised height of up to 356".

16)

Hydraulic Lift Table

View 35 Models

The BMLT has a deck size of 48" min. width to 132" max. length. Capacity ranges from 15,000 to 30,000 lbs. with a raised height of up to 92".

17)

Long Scissor Lift Table

View 8 Models

This BEHLT-TL features a deck size range from a 30" width to 144" length up to a 48” width to 180” length. Medium duty design with capacities ranging from 2,000 to 4,000 lbs. with a raised height up to 58".

18)

Scissor Lift Table

View 12 Models

Our BHLTTL has a deck size of 24" min. width to 216" max. length and features an extra-long platform. Capacity ranges from 2,000 to 12,000 lbs. with a raised height of up to 68".

19)

Heavy Capacity Scissor Lift

View 42 Models

This BMLTDW Lift features heavy-duty steel construction and an extra-wide platform. Capable of bearing loads from 25,000 to 60,000 lbs. and has a raised height of up to 92".

Beacon World Class Long Scissor Lift - BMLTDL series

20)

Hydraulic Platform Lift

View 20 Models

The BMLTDL features a deck size of 48" min. width to 264" max. length. Capacity range is from 30,000 to 60,000 lbs. with a raised height of up to 92".

21)

Heavy Duty Scissor Lift

View 42 Models

The BMLTQD has a deck size of 96" min. width to 264" max. length. Capacities range from 50,000 to 120,000 lbs. with a raised height of up to 92".
