Hand Pallet Jack

Hand Pallet Jack - Low Lift Pallet Truck - BA-LIFT-CB series

Beacon® BA-LIFT-CB Series

The Hand Pallet Jack - Low Lift Pallet Truck with counterbalance design are excellent, cost-effective industrial lifting and transporting equipment. This unit is used to lift materials onto and from shelves and to move items within a facility. This series is operated by a hand-crank winch that has a reversible handle. A worker can invert the forks to provide 2 different heights. Models have two 2" front swivel casters and two 8" non-marking rear wheels.
Starting at: $2,099.97

See chart below and click a model number

Product Details

  • Construction: Constructed of heavy-duty steel and aluminum.
  • Service Range: Models have a lowered height of 2" and a raised height of up to 142".
  • Overall Fork Width: Forks are 4" wide and 22" long (20-1/2" wide overall).
  • Weight: These units weigh 396, 418, or 449 lbs.
  • Capacity: These models feature capacities of 350, 400, and 500 lbs.
  • Options: The Hand Pallet Jack has an optional deck platform available.
  • Surcharge: Due to supply chain disruption, inflation or material shortages - tariffs or surcharges may apply to current published pricing. Some longer lead times may be incurred. Freight charges will be added to published pricing.
  • BA-LIFT-CB360° View
  • BA-LIFT-CB-HP360° View

Documents


Options


Hand Pallet Jack - BA-LIFT-CB Series
Model No. Capacity (LBS) Lowered Height Raised Height Forks Down/Up Size (W x L x H) Price
1) BA-LIFT-CB 500 2" / 21¼" 47" / 67" 29"x47"x68" $2,099.97
2) BA-LIFT-CB-HP 400 2" / 21¼" 97" / 117" 29"x47"x68" $2,372.10
3) BA-LIFT-CB-EHP 350 2" / 21¼" 118" / 142" 29"x47"x68" $2,313.73
OPTION
Model No. Description Size (W x L) Price
4) BA-LIFT-DK Deck Platform 20½"x24¼" $177.93
